Product

Molding Equipment ATOM-FZ
(High-performance mass-production type)

Outline

Auto molding press which has enhanced the uniformity of the surface pressure balance

Feature

  • Achieved machine size reduce by high force press (150 ton)
  • Short distance to mold die and improve accessibility
  • Standard unit of incomplete fill detection unit
  • Press selection available according to production volume
  • Achieved user-friendly operation with graphical user interface
  • Product type conversion available in 30 minutes
  • Press independent operation mechanism
ItemsunitSpecification
Number of presspress123
Machine timesec20
Press clamping forcekN(ton)1470(150)
Transfer forcekN(ton)39.2(4)
Frame sizemm300×100
System sizeWidthmm2,3163,0223,728
Depthmm1,5951,5951,595
Heightmm2,0302,0302,030
Weightkg6,40010,50014,600

※Please note that machine size or weight might be changed based on specifications.

Molding Equipment ATOM-F1N
(Small and medium-sized production, variety change type)

Outline

One frame molding system for small lots and multiple products

Feature

  • High-mix low-volume production support
  • Easy product type conversion and molding die replacement
  • Product type conversion time: about 10 minutes
  • Achieved operation user friendly with graphical user interface
  • Easy transferring with hand lifter due to small-lightweight machine
  • Possesses operating parameters for small quantities, multiple products, and multiple uses
  • E-pin release force detection, Image unfilled detection, abundant optional functions available
ItemsunitSpecification
Number of presspress1
Machine timesecCure+22sec
Press clamping forcekN(ton)396(40)
Transfer forcekN(ton)29.4(3)
Frame sizemm(MIN): 120(L)×20(W), (MAX): 250(L)×75(W)
System sizeWidthmm1,400
Depthmm1,200
Heightmm1,900
Weightkg2,100

※Please note that machine size or weight might be changed based on specifications.

Molding Equipment ATOM-FXG
(High thrust mass production type)

Outline

The high force 150-ton molding press is available to use a large-scale matrix lead frame and to do stably molding

Feature

  • Achieved machine size reduce by high force press (150 ton)
  • Production available in 4 strip/press
  • Short distance to mold die and improve accessibility
  • Standard unit of incomplete fill detection unit
  • Press selection available according to production volume
  • Achieved user-friendly operation with graphical user interface
  • Product type conversion available in 30 minutes
  • Press independent operation mechanism
ItemsunitSpecification
Number of presspress1234
Machine timesec20
Press clamping forcekN(ton)1470(150)
Transfer forcekN(ton)39.2(4)
Frame sizemm260×90
System sizeWidthmm2,0002,6003,2003,800
Depthmm1,5601,5601,5601,560
Heightmm1,9801,9801,9801,980
Weightkg5,5008,50011,50014,500

※Please note that machine size or weight might be changed based on specifications.

Manual Molding Equipment EXP-100
(For testing, semi-automatic type)

Outline

Manual molding system for development and trial purposes

Feature

  • Press force 100ton
  • Available wide lead-frame 80mm
  • The press and the transfer driving is servo motor, and available to set detail parameter
  • The mold die that was used for the trial, can be installed ATOM-FS, FX, and FXG
  • Achieved operation user friendly with graphical user interface
ItemsunitSpecification
Number of presspress1
Press clamping forcekN(ton)980(100)
Transfer forcekN(ton)39.2(4)
Frame sizemm262×80
System sizeWidthmmMain: 730Control box: 550
DepthmmMain: 1,150Control box: 1,004
HeightmmMain: 2,033Control box: 1,400
WeightkgMain: 3,000Control box: 100

※Please note that machine size or weight might be changed based on specifications.

Laser mark Equipment ALM-2600

Outline

Laser mark Equipment is equipped with a dust collector and a cyclone, and is clean by separating the mark area.

Feature

  • The frames are carried one by one, placed on the stage, and printed in the marked area
  • It is equipped with an image sensor for checking characters after the laser mark
  • By exchanging the kit, you can switch the product type
  • It can also be used as a deburring device for the outer frame of the product area
ItemsunitSpecification
Frame sizeWidthmm40~90
lengthmm250(MAX)
Magazine sizemm350(MAX)
System sizeWidthmm1,365
Depthmm1,000
Heightmm1,450
Weightkg900

※Please note that machine size or weight might be changed based on specifications.

Molding frame back tape remover Equipment BTH-101

Outline

It is equipment that stably peels off the back tape remove of the mold lead frame such as QFN

Feature

  • Conditions for removing the tape such as temperature and operating speed can be set
  • The mechanism which detects that the tape is not removed is carried
  • Small and lightweight equipment
ItemsunitSpecification
Frame sizeWidthmm40~80
lengthmm150~250
Thicknessmm0.5~2.0
Peeling speedmm/s1~100
Heat stage temp200(MAX)
System sizeWidthmm900
Depthmm1,100
Heightmm1,800
Weightkg300

※Please note that machine size or weight might be changed based on specifications.

Mold unfilled Equipment AVI

Outline

It is equipment to detect the unfilled part in the package of the mold frame

Feature

  • Creates MAP data that matches the frame pattern, detects unfilled areas, and marks them
  • By exchanging the kit, you can switch the product type
  • In order to prevent users with incorrect settings, we provide a pre-confirmation function for registered products, images, and change kits to be used
  • Small and lightweight equipment
ItemsunitSpecification
Frame sizeWidthmm35~80
Lengthmm125~250
Throughputmm/50frame1~100
Detection size□mm0.2(MIN)
System sizeWidthmm1,000
Depthmm1,230
Heightmm1,650
Weightkg800

※Please note that machine size or weight might be changed based on specifications.

Read frame counter

Outline

A handy type, cordless lead frame counter.

Feature

  • You can easily count the number of lead frames by sliding while pressing the button
  • It is a handy type and cordless, so it is easy to carry.
  • Small and lightweight type. registered products, images, and change kits to be used
ItemsunitSpecification
Detection specificationsResponse timems1~5
Frame thicknessmm0.1(MIN)
Frame-to-frame pitchmm0.5(MIN)
Power supply (battery)Rechargeable nickel-metal hydride rechargeable battery[9V]
System sizeWidthmm165
Depthmm25
Heightmm100
Weightg320

※Please note that machine size or weight might be changed based on specifications.

Molding dies, precision parts processing

Outline

We manufacture precision molds using the technology cultivated through many years of
experience and precision processing.
We will make proposals that suit our customers based on our track record of providing
mold materials and surface treatments to various industries.

Mold process analysis system(data creation)

Outline

Using our highly heat-resistant, compact pressure sensor and analysis software, we analyze and provide data on the pressure of the resin generated in the mold and the force generated when the frame after molding separates from the mold.
It provides data such as graphs and numerical values of differences in molding resin and differences in continuous shots.

事業紹介

Focusing on ultra-precision processing technology, we are developing four businesses: semiconductor assembly business, plastic molding business, equipment business, and automotive parts business. Our strength is that we can develop new products that combine each other's technologies and build highly efficient production lines using our unique technologies while developing our business independently.
